Tehnične informacije Portable Recorder Number of Tracks WAV: 8 (6 Inputs Stereo Mix) Max Sample Rate/Resolution 192 kHz / 32-Bit Microphone None Built-In Speaker None Display Color LCD (Backlit) Memory Card Support SD, SDHC, SDXC (Up to 512 GB) Internal Storage None Recording Audio File Formats BWF, MP3, WAV, iXML Sample Rates WAV: 44.1 / 47.952 / 48 / 48.048 / 88.2 / 96 / 192 kHz Bit Depth 16 / 24 / 32-Bit Bit Rates 128 to 320 kb/s Signal Processing Limiter Timecode Yes Frame Rates Supported 23.976 / 24 / 25 / 29.97 / 29.97 DF / 30 / 30 DF Clock Accuracy ±0.2 ppm (Timecode) Recording Time WAV 48 kHz/24-Bit: 57.69 Mins per GB (Stereo) WAV 192 kHz/24-Bit: 14.41 Mins per GB (Stereo) Connectivity Analog I/O 6 x XLR 3-Pin Female Balanced Line/Mic Input (Lockable) 1 x 1/8″ / 3.5 mm TRS Female Unbalanced Line Output 1 x 1/8″ / 3.5 mm TRS Female Unbalanced Headphone Output Digital I/O 1 x 1/8″ / 3.5 mm TRS Timecode In/Out Phantom Power 24 / 48 V Phantom Power Current ≤10 mA per Channel Host Connection 1 x USB Type-C (I/O, USB 2.0) Performance Gain Range Mic Inputs: 12 to  75 dB Line Inputs: 8 dB to  55 dB Max Input Level Mic Inputs: 4 dBu Line Inputs: 24 dBu Max Output Level Line Outputs: 10 dBV Headphone Output Power 100 mW per Channel into 32 Ohms Dynamic Range Line Outputs: 95 dB Headphone Outputs: 108 dB Impedance Mic Inputs: ≥3 kOhms Line Inputs: ≥5 kOhms Line Outputs: ≤100 Ohms Headphone Outputs: ≤15 Ohms Timecode Input: 4.6 kOhms Timecode Output: ≤50 Ohms EIN ≤-127 dBu (A-Weighted) Power Power Options Batteries or AC/DC Power Adapter Battery Type 4 x AA (Included) 1 x L Series (Not Included) Approximate Battery Life WAV 48 kHz/16-Bit: 7.5 Hours (Alkaline, 2 Channels, Backlit Display, Phantom Off, with Headphones) 10.5 Hours (NiMH, 2 Channels, Backlit Display, Phantom Off, with Headphones) 16.5 Hours (Lithium, 2 Channels, Backlit Display, Phantom Off, with Headphones) WAV 48 kHz/24-Bit: 5 Hours (Alkaline, All Channels, Backlit Display, Phantom Off, with Headphones) 7 Hours (NiMH, All Channels, Backlit Display, Phantom Off, with Headphones) 10.5 Hours (Lithium, All Channels, Backlit Display, Phantom Off, with Headphones) WAV 192 kHz/24-Bit: 0.5 Hours (Alkaline, All Channels, Backlit Display, Phantom On, with Headphones) 1.5 Hours (NiMH, All Channels, Backlit Display, Phantom On, with Headphones) 3.5 Hours (Lithium, All Channels, Backlit Display, Phantom On, with Headphones) AC/DC Power Adapter 5 VDC (Not Included) Physical Dimensions 3.9 x 2.5 x 4.7″ / 100 x 62.9 x 119.8 mm Weight 1.2 lb / 530 g
